Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
298
Example:
features.dnd.on_code = *71
Note: It works only if “features.dnd.allow” is set to 1 (Enabled) and the value of the parameter “fea-
tures.dnd_mode” is set to 0 (Phone) (except T19(P) E2/CP920 IP phones).
Permitted
Values
String within 32 characters
Default Blank
Web UI Features->Forward&DND->DND->On Code
Phone UI Menu->Features->DND->On Code
Parameter features.dnd.off_code <y0000000000xx>.cfg
Description
It configures the DND off code to deactivate the server-side DND feature. The IP phone will send the DND
off code to the server when you deactivate DND feature on the IP phone.
Example:
features.dnd.off_code = *72
Note: It works only if “features.dnd.allow” is set to 1 (Enabled) and the value of the parameter “fea-
tures.dnd_mode” is set to 0 (Phone) (except T19(P) E2/CP920 IP phones).
Permitted
Values
String within 32 characters
Default Blank
Web UI Features->Forward&DND->DND->Off Code
Phone UI Menu->Features->DND->Off Code
DND in Custom Mode Configuration
The following table lists the parameters you can use to configure DND in Custom mode.
Parameter
account.X.dnd.enable
[1]
<MAC>.cfg
Description
It triggers the DND feature to on or off.
Note: It works only if “features.dnd.allow” is set to 1 (Enabled) and value of the parameter “features.dnd_
mode” is set to 1 (Custom). It is not applicable to T19(P) E2/CP920 IP phones.
Permitted
Values
0-Off
1-On, the IP phone will reject incoming calls on account X.
Default 0
Web UI Features->Forward& DND->DND->AccountX->DND Status
Phone UI Menu->Features->DND->AccountX->DND Status
Parameter
account.X.dnd.on_code
[1]
<MAC>.cfg
Description
It configures the DND on code to activate the server-side DND feature.
The IP phone will send the DND on code to the server when you activate DND feature on the IP phone.
Example:
