YOKOGAWA AQ7260 OTDR User Manual

Chapter 3 PERFORMING MEASUREMENTS
3-79
4. Locate the cursor on the desired event by turning the rotary knob.
Events (T) indicate the following positions.
Positive splice loss Negative splice loss Reflection
5. Press [F2] (
2
).
“
2
” will appear at the cursor position.
Markers
1
, Y2 and
3
will be set when
2
marker is displayed.
The splice loss will be displayed.
T
T
T
Distance from the origin to each marker
Splice loss
