YOKOGAWA AQ7260 OTDR User Manual

Chapter 5 EDITING AUTOMATIC SEARCH RESULTS
5-4
4. Press [ENTER].
The following screen will appear.
5. Press [F2] (EVENT EDIT).
6. Locate the cursor to the point where an event is to be inserted by turning the
rotary knob.
If necessary, enlarge the trace.
•For the method of moving the cursor, refer to page 3-64.
•For the method of enlarging the trace, refer to page 3-66.
Information regarding
the current event is
displayed.
An event is to be inserted here.
Refer
