Chapter 8 USING OPTIONS AND EXTERNAL DEVICES
8-24
2. Open the cover on the top of the instrument.
3. Connect the USB connector of the connecting cable to a USB connector (host
side) on the instrument.
Two USB connectors (host side) are available, and the personal computer can be
connected to either of these.
4. Connect the RS-232C connector of the cable to the personal computer.
TIP
