Function Keys and Hierarchy Level Display
When [MODE] is pressed, the function menu for currently selected mode will be displayed.
The function keys are displayed in one of the three shapes, for each of which execution
format has been set.
Execution format for each shape is explained below.
Shape Description
When a function key of this shape is pressed, a function window
(lower-hierarchy window) relating to the function will appear.
The number of tags indicating the hierarchy level is also increased by
one. To return to the previous hierarchy level, press [ESC]
* 1
When a function key of this shape is pressed, a window allowing you to
change the currently set values or setting conditions will appear.
When a function key of this shape is pressed, the function indicated on
the key will be executed.
* 1
Higher
hierarchy
level
Lower
hierarchy
level
[ESC]
[ESC]
[ESC]
