13.2 Commands
13-12
IM GS210-01EN
:SOURce:LEVel:AUTO/?
Function Sets or queries the source level in terms of the
most appropriate range.
Syntax
:SOURce:LEVel:AUTO <
voltage
>|<
current
>|
MINimum|MAXimum
<voltage>
Specify a voltage level.
The source level is set to
the smallest source range
that includes the specified
voltage.
Y
ou have to set the source
function to voltage before
sending this command.
<current> Specify a current level.
The source level is set to
the smallest source range
that includes the specified
current.
You have to set the source
function to current before
sending this command.
MINimum Sets the source range to
the maximum range and
the source level to the
minimum value.
MAXimum Sets the source range to
the maximum range and
the source level to the
maximum value.
:SOURce:LEVel:AUTO?
[MINimum|MAXimum]
MINimum The minimum level.
MAXimum The maximum level.
→<voltage>|<current> Thesourcelevelthat
is being produced.
Example
:SOUR:LEV:AUTO 1.5
:SOUR:LEV:AUTO?
Description During program editing, this command sets or
queries the current step’
s source level. If you set
the current step’s source level, program editing
will proceed to the next step.
:SOURce:PROTection:VOLTage/?
Function Sets or queries the voltage limiter level.
Syntax
:SOURce:PROTection:VOLTage <
voltage
>|
MINimum|MAXimum
<voltage> Specify a voltage limiter
level.
MINimum Sets the voltage limiter
level to ±1 V.
MAXimum Sets the voltage limiter
level to ±30 V.
:SOURce:PROTection:VOLTage?
[MINimum|MAXimum]
MINimum
+1E+0
MAXimum
+30E+0
<voltage> The voltage limiter level
that is being used.
Example
:SOUR:PROT:VOLT 14
:SOUR:PROT:VOLT?
:SOURce:PROTection:CURRent/?
Function Sets or queries the current limiter level.
Syntax
:SOURce:PROTection:CURRent <
current
>|
MINimum|MAXimum
<current> Specify a current limiter
level.
MINimum Sets the current limiter
level to ±1 mA.
MAXimum Sets the current limiter
level to ±200 mA.
:SOURce:PROTection:CURRent?
[MINimum|MAXimum]
MINimum
+1E-3
MAXimum
+200E-3
<current> The current limiter level
that is being used.
Example
:SOUR:PROT:CURR 13E-3
:SOUR:PROT:CURR?
