Instrument Errors (100 and higher)
Error No. Error Message Corrective Action Page
100 Program is not defined Select a different program file, or edit the program, 6-5
and then run it.
101 Program is not being edited You can only end program editing when a program 6-5
is being edited.
103 Program is being edited You cannot change GS200 settings or run a 6-5
program when a program is being edited.
104 Illegal file Check that the file is correct. 6-9, 9-2,
105 CSV format may be incorrect Check the CSV-format setting. 9-6
106 Trigger source is M.End When the trigger is M.End, you cannot use RUN 6-4
and STEP to perform program execution.
107 Stopped because function has changed Change the source function to match the program, 6-5
and execute the program again.
108 Turn OUTPUT on to execute program Turn output on to execute the program. 6-12
109 Illegal calibration Servicing is necessary. —
110 Illegal program function Make sure that a program only contains the same —
functions.
111 Illegal zero calibration Servicing is necessary. —
200 Power-on setup lost There is no setup file. Specify the setup file 9-4
correctly.
201 Failed to read serial number Restart the GS200. —
If the error still appears, servicing is necessary.
202 Failed to read system parameters Settings such as the communication settings have —
been reset to the factory default settings, so set
them back to the correct settings. If the same error
continues to appear, servicing is required.
203 Cannot save file Check that there is data to save and that the file is 9-2
not set to read-only.
204 Cannot load file Check that there is a file to load and that the 9-2
contents of the file are correct.
205 Cannot delete file Check that there is a file to delete and that the file 9-2
is not set to read-only.
300 An abnormal load is connected Connect a load that is within the specifications. —
303 Low battery Request to have the battery replaced, because the —
timestamp when creating files will not be correct.
304 Failed to detect the line frequency Make sure that the power source is stable, and —
restart the GS200.
500 Storing has not finished yet Wait for the storage operation to complete (the 7-8
EOT bit becomes 1) before you start it again.
600 CPU board error Restart the GS200. If the error still appears, —
601 servicing is necessary. When you send the GS200
602 off for servicing, inform the service technician of
603 the error number.
604
14.2 Error Code Descriptions and Corrective Actions
14-5
IM GS210-01EN
Troubleshooting and Maintenance
