Explanation
USB Storage Feature
For details on the USB storage feature, see section 2.8.
GS200ROM
GS200ROM is a 4 MB non-volatile disk with preset folders for different purposes. Files
are stored in the appropriate folders.
• PROGRAM
The PROGRAM folder stores program files that you can select when you want to
execute a program.
When the GS200 is sent from the factory or when the disk is formatted, two sample
program files are stored in this folder
.
• SETUP
The SETUP folder stores the GS200 panel setup data that is s
elected when settings
are loaded.
When the GS200 is sent from the factory or when the disk is formatted, a sample
setup file is stored in this folder.
GS200RAM
GS200RAM is a 16 MB RAM disk that is automatically formatted when the power is
turned on. It is a volatile disk that is used to exchange files with a PC. The result file (Result.
csv) is stored on this disk when the storage operation is carried out. Saved result files
can be read from a PC.
When you update the system firmware, system files are written to GS200RAM from your
PC. For details, see section 14.5, “Updating the System Firmware.”
4.4 USB Storage Feature
4-9
IM GS210-01EN
