Explanation
You can create and edit programs from:
• The GS200.
• A PC.
Creating and Editing Programs from the GS200
The Program Editing Screen
New Line
This is displayed when you are currently editing a new step (the step after the last step).
You can add new steps to the program by editing this step.
Creating a New Program
When you create a new program, the initial source level value is 0 V or 0 mA.
Editing Programs
When you create a program on the GS200, the program is displayed on the screen.
When you load an existing program onto the GS200, the program is displayed on the
screen.
Creating and Editing Programs from a PC
Number of Steps
A program can contain up to 10000 steps. If you use a PC to create a program that
contains more than 10000 steps, the GS200 will only load the first 10000 steps.
<<Corresponding Command Mnemonic>>
:PROGram:EDIT:STARt
:PROGram:EDIT:END
:SOURce:FUNCtion VOLTage|CURRent
:SOURce:RANGe <voltage>|MINimum|MAXimum|UP|DOWN
:SOURce:RANGe <current>|MINimum|MAXimum|UP|DOWN
:SOURce:LEVel[:FIX] <voltage>|MINimum|MAXimum
:SOURce:LEVel[:FIX] <current>|MINimum|MAXimum
:SOURce:LEVel:AUTO <voltage>|MINimum|MAXimum
:SOURce:LEVel:AUTO <current>|MINimum|MAXimum
6.5 Creating and Editing Programs
6-7
IM GS210-01EN
