Bit-0toBit-2ofProgramPatternNumber(PT.B0toPT.B2)
The program pattern number can be switched using contact input. There are three
methods to specify program pattern number.
• Status switch 1 (Operation by keystroke or via communication is enabled depending
on the conditions.)
Program pattern
number
Contact status
PT.B2 PT.B1 PT.B0
1 OFF OFF ON
2 OFF ON OFF
3 OFF ON ON
4 ON OFF OFF
*1: “1” when the contact input is turned on and “0” when turned off.
*2: Program pattern number can be switched by keystroke or via communication when all contact
inputs of PT.B0 to PT.B2 are turned off.
*3: Program pattern number cannot be switched by keystroke or via communication when any
contact input of PT.B0 to PT.B2 is turned on.
*4: The contact input is turned off when the bit of program pattern number is not assigned to the
contact input.
*5: The immediately preceding program pattern number is held when all contact inputs are turned
off.
• Status switch 2 (Operation by keystroke or via communication is disabled.)
Program pattern
number
Contact status
PT.B2 PT.B1 PT.B0
1
OFF OFF OFF
2
OFF OFF ON
3
OFF ON OFF
4
OFF ON ON
*1: “1” when the contact input is turned on and “0” when turned off.
*2: Contact input is turned off when the bit of program pattern number is not assigned to the contact
input.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
PT.BC
Bit changing method
of program pattern
number
PRO
0: Status switch 1
1: Status switch 2
DI.NU
12.1SettingContactInputFunction
