12-6
IM 05P02D41-01EN
Bit-0toBit-2ofManualPresetOutputNumber(MP.B0toMP.B2)
The manual preset output number can be switched using contact input. There are two
methods to specify a manual preset output number.
• Status switch 1 (Operation by keystroke or via communication is enabled depending
on the conditions.)
Manual preset
output number
Contact status
MP.B2 MP.B1 MP.B0
1 OFF OFF ON
2 OFF ON OFF
3 OFF ON ON
4 ON OFF OFF
5 ON OFF ON
*1: “1” when the contact input is turned on and “0” when turned off.
*2: Manual preset output number can be switched by keystroke via communication when all contact
inputs of MP.B0 to MP.B2 are turned off.
*3: Manual preset output number cannot be switched by keystroke or via communication when any
contact input of MP.B0 to MP.B2 is turned on.
*4: The contact input is turned off when the bit of manual preset output number is not assigned to
the contact input.
• Status Switch 2 (Operation by keystroke or via communication is disabled.)
Manual preset
output number
Contact status
MP.B2 MP.B1 MP.B0
1 OFF OFF OFF
2 OFF OFF ON
3 OFF ON OFF
4 OFF ON ON
5 ON OFF OFF
*1: “1” when contact input is turned on and “0” when turned off.
*2: The contact input is turned off when the bit of manual preset output number is not assigned to
the contact input.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
MP.BC
Bit changing method of
manual preset output
number
PRO
0: Status switch 1
1: Status switch 2
DI.NU
12.1SettingContactInputFunction
