YOKOGAWA UP35A User Manual

12-14
IM 05P02D41-01EN
OperationModeandStatus
Setpoint Function
Contact status
ON OFF
4177 AUTO/MAN MAN AUTO
4181 Stop of program operation RESET (OFF→ON) –
4182 Start of program operation PROG (OFF→ON) –
4183 Start of local operation LOCAL (OFF→ON) –
4189 Start of hold operation HOLD (OFF→ON) –
4190 Waitag Wait command (ON)
Wait release
command (OFF)
4191 During auto-tuning During AT –
4265 Pattern end signal (1 s.) Pattern end –
4266 Pattern end signal (3 s.) Pattern end –
4267 Pattern end signal (5 s.) Pattern end –
4257 Wait end signal (1 s.) Wait end –
4258 Wait end signal (3 s.) Wait end –
4259 Wait end signal (5 s.) Wait end –
4209 Duringautomaticvalveadjustment Duringadjustment –
4261 Controlagforsegmenttransition Wait command (ON)
Wait release
command (OFF)
4210
During operartion by the valve position
estimating type
During operation by
estimating type
During operation by
feedback input
4213 Valve is open Open –
4214 Valve is closed Closed –
4256 FAIL output Normal status FAIL status
SystemErrorStatus
Setpoint Function
Contact status
ON OFF
4529 Heater break alarm 1 status Alarm occurs Normal
4530 Heater break alarm 2 status Alarm occurs Normal
4769 Message display interruption 1 status With interruption Without interruption
4770 Message display interruption 2 status With interruption Without interruption
4771 Message display interruption 3 status With interruption Without interruption
4773 Message display interruption 4 status With interruption Without interruption
12.2SettingContactOutputFunction
