Contact Input/Output Functions

ErrorStatus

Setpoint Function

Contact status

ON OFF

4065 PV input ADC error

Error occurs Normal

4073 PV input burnout error

4070 PV input RJC error

4081

Feedback resistance/current

burnout

4082

Automatic valve position

adjustmenterror

4097 PV input burnout error

4101 PV input over-scale

4102 PV input under-scale

4111 Auto-tuning time out

SystemErrorStatus

Setpoint Function

Contact status

ON OFF

4001 System data error

Error occurs Normal

4002 Calibration value error

4003 User (parameter) default value error

4005 Setup parameter error

4006 Operation parameter error

4017 Corrupted ladder program

4018 Laddercalculationoverow

4019 Ladder program error

4021 Load factor over 100%

4022 Load factor over 200%

4009 Faulty FRAM
