Parameter X400

Displayeddigit bit Description

1st digit

0 DI41 status (0: OFF, 1: ON)

1 DI42 status (0: OFF, 1: ON)

2 DI43 status (0: OFF, 1: ON)

3 DI44 status (0: OFF, 1: ON)

2nd digit

4 DI45 status (0: OFF, 1: ON)

5 –

6 –

7 –

3rd digit

8 –

9 –

10 –

11 –

4th digit

12 –

13 –

14 –

15 –

Parameter Y000

Displayeddigit bit Description

1st digit

0 AL1 status (0: OFF, 1: ON)

1 AL2 status (0: OFF, 1: ON)

2 AL3 status (0: OFF, 1: ON)

3 –

2nd digit

4 –

5 –

6 –

7 –

3rd digit

8 –

9 –

10 –

11 –

4th digit

12 –

13 –

14 –

15 –

Parameter Y100

Displayeddigit bit Description

1st digit

0 DO11 status (0: OFF, 1: ON)

1 DO12 status (0: OFF, 1: ON)

2 DO13 status (0: OFF, 1: ON)

3 DO14 status (0: OFF, 1: ON)

2nd digit

4 DO15 status (0: OFF, 1: ON)

5 –

6 –

7 –

3rd digit

8 –

9 –

10 –

11 –

4th digit

12 –

13 –

14 –

15 –

13.4ConfirmationofKeyandI/OConditionandVersion
