IM 05P02D41-01EN
Display
, Key
, and Security Functions
Parameter Y400
Displayeddigit
bit
Description
1st digit
0
DO41 status (0: OFF
, 1: ON)
1
DO42 status (0: OFF
, 1: ON)
2
DO43 status (0: OFF
, 1: ON)
3
DO44 status (0: OFF
, 1: ON)
2nd digit
4
DO45 status (0: OFF
, 1: ON)
5
–
6
–
7
–
3rd digit
8
–
9
–
10
–
11
–
4th digit
12
–
13
–
14
–
15
–
13
13.4ConfirmationofKeyandI/OConditionandV
ersion
293
295
