1-10

IM 05P02D41-01EN

PROFIBUS-DPCommunication

The UP35A can be used as the slave devices for PROFIBUS-DP communication. Read-

out of PV, operation or alarm status, and SP setting can be done by accessing the

remote I/O on the master unit of PROFIBUS-DP.

Max. 1200 m, number of connected slaves: 31

PLC

PROFIBUS-DP communication

PROFIBUS-DP Master

PROFIBUS-DP Slave / Modbus Master

Modbus Slave Modbus Slave Modbus Slave Modbus Slave

Modbus/RTU communication

DeviceNet Communication

The UP35A can be used as the slave devices for DeviceNet communication. Read-out of

PV, operation or alarm status, and SP setting can be done by accessing the remote I/O

on the master unit of DeviceNet.

Max. 1200 m, number of connected slaves: 31

PLC

DeviceNet communication

DeviceNet Master

DeviceNet Slave / Modbus Master

Modbus Slave Modbus Slave Modbus Slave Modbus Slave

Modbus/RTU communication

1.7 Communication Functions
