18-3
IM 05P02D41-01EN
Parameters
18
The parameters in the menu of the following table indicate the parameters to set the
basic functions of the controller. The symbol in parentheses are shown on Group display.
Menusymbol Functions
PASS Password setting (Displayed only when the password has been sent.)
Menusymbol Functions
CTL Control type, sampling period, segment setting method, program time unit, etc
PV PV input type, range, scale, etc
MPV Input range, SP limiters, etc.
OUT Controloutputtype,valvepositionadjustment,retransmissionoutput,etc.
HBA Heater break alarm
R485 (E1 or E3) RS-485 communication (E1-terminal area for UP32A, E3-terminal area for UP35A)
ETHR (E3) Ethernet communication, gateway setting, IP access restriction, etc. (E3-terminal area)
PROF (E3) PROFIBUS-DP communication (E3-terminal area)
DNET (E3) DeviceNet communication (E3-terminal area)
CC-L (E1 or E3) CC-Link communication (E1-terminal area for UP32A, E3-terminal area for UP35A)
KEY Function of User function key
DISP Display functions
CSEL SELECT Display, SELECT parameter registration
KLOC Key lock
MLOC Parameter menu lock
DI.SL Contact input function
DI.NU Contact input function (bit selection)
DI.D Contact input type (equipped as standard)
DI.D (E1) Contact input type (E1-terminal area)
DI.D (E4) Contact input type (E4-terminal area)
ALM Alarm output function, contact output type (equipped as standard)
DO (E1) Contact output function, contact output type (E1-terminal area)
DO (E4) Contact output function, contact output type (E4-terminal area)
I/O Input / output data display
SYS Action setting when recovering from a power failure, guide display language, password setting, etc
INIT Initializationofparameter
VER Error status, version, MAC address, etc
LVL Parameter display level
Note
Some parameters are not displayed according to the setting such as control type, or input and
output.
18.1 Parameter Map
