18-12
IM 05P02D41-01EN
LocalSettingMenu(Menu:LOC)
Parameter
symbol
Name
Display
level
Settingrange
Initial
value
LSP
Local target
setpoint
EASY
0.0 to 100.0% of PV input range (EU)
(Setting range: P.RL to P.RH)
P.RL
L.PID
PID number
selection
for local-mode
operation
EASY
Set a PID group number to use.
1 to 4
* Available only for the L.PID when ZON = 0
or 5.
* If set to “Local PID selection,” local PID
is selected irrespective of the operation
modes.
1
L.TY1 to
L.TY4
Local event-1
to -4 type
STD
OFF: Disable
(Energized)
1: PV high limit,
2: PV low limit,
3: SP high limit,
4: SP low limit,
5: Deviation high limit,
6: Deviation low limit,
7: Deviation high and low limits,
8: Deviation within high and low limits,
9: Target SP high limit,
10: Target SP low limit,
11: Target SP deviation high limit,
12: Target SP deviation low limit,
13: Target SP deviation high and low limits,
14: Target SP deviation within high and low
limits,
15: OUT high limit,
16: OUT low limit,
17: Cooling-side OUT high limit,
18: Cooling-side OUT low limit
*Add100for"de-energized".Forexample,
whenthePVhighlimitisde-energized,
the setting is 101.
OFF
L.EV1 to
L.EV2
Local event-1
to -2 setpoint
STD
Set a display value of setpoint of PV alarm,
SP alarm, deviation alarm, or output alarm.
-19999 to 30000 (Set a value within the
input range.)
Decimal point position depends on the input
type
0
18.2ListofParameters
