Parameters
18
Program Editing Menu (Menu: EDIT)
Parameter
symbol
Name
Display
level
Settingrange
Initial
value
ALL.S
Number of
remaining unused
segments
PRO
0 to 20 (40 when the option “/AP” is
specied.)
(Display only)
20 (40)
PTN.S
Pattern number
designation for
comrmingnumber
of segments
PRO
Specify the numbers of program pattern
to display in parameter USE.S.
1 to 2 (4 when the option “/AP” is
specied.)
0
USE.S
Number of
segments within a
pattern
PRO
Can be displayed when the parameter
number specify in parameter PTN.S.
(Display only)
0: disable
1 to 20 (40 when the option “/AP” is
specied.)
-
CPY.S
Source-of-copying
pattern number
designation
PRO
Specify the number of the source-of-
copying program pattern. (1 to 2 (4 when
theoption“/AP”isspecied.))
0
CPY.D
Target-of-copying
pattern number
designation
PRO
Specify the target-of-copying program
pattern. (1 to 2 (4 when the option “/AP” is
specied.))
0
CLR.P
Program pattern
clearance
PRO
Specify the number of the program pattern
to be cleared. (1 to 2 (4 when the option
“/AP”isspecied.))
0
AlarmSetpointSettingMenu(Menu:AL)
Parameter
symbol
Name
Display
level
Settingrange Initial value
A1 to A4
Alarm-1 to -4
setpoint
EASY
These alarms work irrespective of
the operation mode.
Set a display value of setpoint of
PV alarm, SP alarm, deviation
alarm, output alarm, or velocity
alarm.
-19999 to 30000 (Set a value
within the input range.)
Decimal point position depends on
the input type.
0
SP-relatedSettingMenu(Menu:SPS)
Parameter
symbol
Name
Display
level
Settingrange Initial value
SPT
SP tracking
selection
STD
OFF, ON
Tracking is performed when the
mode changes from Program to
Local. (The local setpoint keeps
track of the program setpoint.)
OFF
S.TM
Starting time of
program operation
STD
0.00 to 999.59 (“hour.minute” or
“minute.second” (common use of
instrument)
* Use the parameter TMU to set
the time unit.
0.00
PNC
Program pattern
number clearance
STD
OFF: Not cleared.
ON: Cleared. (Set the program
No. before restart program
operation)
* The controller resets (clears) the
program pattern number on the
operating display to “0” at the
end of program operation.
OFF
