YOKOGAWA UP35A User Manual

18-14
IM 05P02D41-01EN
AlarmFunctionSettingMenu(Menu:ALRM)
Parameter
symbol
Name
Display
level
Settingrange Initial value
EHY1 to
EHY2
Event-1 to -2
hysteresis
STD
The hysteresis setpoint of PV event or
Local event is set to the parcentage of
0.0 to 100.0%.
The setting value (%) is for the PV input
range span or output span.
0
AL1 to AL2
Alarm-1 to -2
type
EASY
These alarms work irrespective of the
operation mode.
Set a 5-digit value in the following order.
[Latchaction(0/1/2/3/4)]+[Energized(0)
orDe-energized(1)]+[Without(0)or
With (1) Stand-by action] + [Alarm type:
2 digits (see below)]
For latch action, see chapter 11.
Alarm type: 2 digits
00: Disable
01: PV high limit
02: PV low limit
03: SP high limit
04: SP low limit
05: Deviation high limit
06: Deviation low limit
07: Deviation high and low limits
08: Deviation within high and low limits
09: Target SP high limit
10: Target SP low limit
11: Target SP deviation high limit
12: Target SP deviation low limit
13:
Target SP deviation high and low limits
14: Target SP deviation within high and
low limits
15: OUT high limit
16: OUT low limit
17: Cooling-side OUT high limit
18: Cooling-side OUT low limit
19: Analog input PV high limit
20: Analog input PV low limit
27: Feedback input high limit
28: Feedback input low limit
29: PV velocity
30: Fault diagnosis
31: FAIL
AL1:
Latch action
(0)
Energized(0)
Without Stand-
by action (0)
PV high limit
(01)
AL2:
Latch action
(0)
Energized(0)
Without Stand-
by action (0)
PV low limit
(02)
18.2ListofParameters
