18-15
IM 05P02D41-01EN
Parameters
18
AlarmFunctionSettingMenu(Menu:ALRM)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initial value
VT1 to VT2
PV velocity
alarm time
setpoint 1 to 2
EASY 0.01 to 99.59 (minute.second) 1.00
HY1 to HY2
Alarm-1 to -2
hysteresis
EASY
Set a display value of setpoint of
hysteresis.
-19999 to 30000 (Set a value within the
input range.)
Decimal point position depends on the
input type.
When the decimal point position for the
input type is set to "1", the initial value
of the hysteresis is "1.0".
10
DYN1 to
DYN2
Alarm-1 to -2
On-delay timer
STD
0.00 to 99.59 (minute.second)
0.00
DYF1 to
DYF2
Alarm-1 to -2
Off-delay timer
PRO 0.00
AMD Alarm mode STD
0: Always active
1: Not active in RESET mode
2: Not active in RESET or MAN mode
0
18.2ListofParameters
