YOKOGAWA UP35A User Manual

18-16
IM 05P02D41-01EN
PV-relatedSettingMenu(Menu:PVS)
Parameter
symbol
Name
Display
level
Settingrange Initial value
BS PV input bias EASY
-100.0 to 100.0% of PV input range
span (EUS)
0.0 % of PV
input range
span
FL PVinputlter EASY OFF, 1 to 120 s OFF
PIDSettingMenu(Menu:PID)
Parameter
symbol
Name
Display
level
Settingrange Initial value
P
Proportional band
Heating-side
proportional band
(in Heating/cooling
control)
EASY
0.0 to 999.9%
When 0.0% is set, it operates as
0.1%.
Heating-side ON/OFF control
applies when 0.0% in Heating/
cooling control
5.0%
I
Integral time
Heating-side
integral time (in
Heating/cooling
control)
EASY
OFF: Disable
1 to 6000 s
240 s
D
Derivative time
Heating-side
derivative time (in
Heating/cooling
control)
EASY
OFF: Disable
1 to 6000 s
60 s
OH
Control output high
limit
Heating-side control
output high limit
(in Heating/cooling
control)
EASY
-4.9 to 105.0%, (OL<OH)
In Heating/cooling control: 0.1 to
105.0% (OL<OH)
100.0%
OL
Control output low
limit
Heating-side control
output low limit (in
Heating/cooling
control)
EASY
-5.0 to 104.9%, (OL<OH), SD:
Tight shut
In Heating/cooling control: 0.0 to
104.9% (OL<OH)
0.0%
MR Manual reset EASY
Enabled when integral time is OFF.
The manual reset value equals the
output value when PV = SP.
-5.0 to 105.0%
50.0%
HYS
Hysteresis (in
ON/OFF control,
or Position
proportional control)
Heating-side
ON/OFF control
hysteresis (in
Heating/cooling
control)
EASY
In ON/OFF control: 0.0 to 100.0%
of PV input range span (EUS)
In Heating/cooling control or
Position proportional control: 0.0 to
100.0%
In ON/OFF
control: 0.5
% of PV input
range span
In Heating/
cooling control
or Position
proportional
control: 0.5 %
HY.UP
Upper-side
hysteresis (in ON/
OFF control)
EASY
0.0 to 100.0% of PV input range
span (EUS)
0.5 % of PV
input range
span
HY.LO
Lower-side
hysteresis (in ON/
OFF control)
EASY
0.5 % of PV
input range
span
DR
Direct/reverse
action switch
STD
RVS: Reverse action, DIR: Direct
action
RVS
18.2ListofParameters
