YOKOGAWA UP35A User Manual

18-21
IM 05P02D41-01EN
Parameters
18
PVInputSettingMenu(Menu:PV)
Parameter
symbol
Name
Display
level
Settingrange
Initial
value
IN PV input type EASY
OFF: Disable
K1: -270.0 to 1370.0 (°C) / -450.0 to 2500.0 (°F)
K2: -270.0 to 1000.0 (°C) / -450.0 to 2300.0 (°F)
K3: -200.0 to 500.0 (°C) / -200.0 to 1000.0 (°F)
J: -200.0 to 1200.0 (°C) / -300.0 to 2300.0 (°F)
T1: -270.0 to 400.0 (°C) / -450.0 to 750.0 (°F)
T2: 0.0 to 400.0 (°C) / -200.0 to 750.0 (°F)
B: 0.0 to 1800.0 (°C) / 32 to 3300 (°F)
S: 0.0 to 1700.0 (°C) / 32 to 3100 (°F)
R: 0.0 to 1700.0 (°C) / 32 to 3100 (°F)
N: -200.0 to 1300.0 (°C) / -300.0 to 2400.0 (°F)
E: -270.0 to 1000.0 (°C) / -450.0 to 1800.0 (°F)
L: -200.0 to 900.0 (°C) / -300.0 to 1600.0 (°F)
U1: -200.0 to 400.0 (°C) / -300.0 to 750.0 (°F)
U2: 0.0 to 400.0 (°C) / -200.0 to 1000.0 (°F)
W: 0.0 to 2300.0 (°C) / 32 to 4200 (°F)
PL2: 0.0 to 1390.0 (°C) / 32.0 to 2500.0 (°F)
P2040: 0.0 to 1900.0 (°C) / 32 to 3400 (°F)
WRE: 0.0 to 2000.0 (°C) / 32 to 3600 (°F)
JPT1: -200.0 to 500.0 (°C) / -300.0 to 1000.0 (°F)
JPT2: -150.00 to 150.00 (°C) / -200.0 to 300.0 (°F)
PT1: -200.0 to 850.0 (°C) / -300.0 to 1560.0 (°F)
PT2: -200.0 to 500.0 (°C) / -300.0 to 1000.0 (°F)
PT3: -150.00 to 150.00 (°C) / -200.0 to 300.0 (°F)
0.4-2V: 0.400 to 2.000 V
1-5V: 1.000 to 5.000 V
4-20: 4.00 to 20.00 mA
0-2V: 0.000 to 2.000 V
0-10V: 0.00 to 10.00 V
0-20: 0.00 to 20.00 mA
-1020: -10.00 to 20.00 mV
0-100: 0.0 to 100.0 mV
Note:
W: W-5% Re/W-26% Re (Hoskins Mfg. Co.),
ASTM E988
WRE: W97Re3-W75Re25
OFF
UNIT PV input unit EASY
-: No unit
C: Degree Celsius
-: No unit
--: No unit
---: No unit
F: Degree Fahrenheit
C
RH
Maximum
value of PV
input range
EASY
Depends on the input type.
- For temperature input -
Set the temperature range that is actually
controlled. (RL<RH)
- For voltage / current input -
Set the range of a voltage / current signal
that is applied.
The scale across which the voltage / current
signal is actually controlled should be set
using the maximum value of input scale (SH)
and minimum value of input scale (SL).
(Input is always 0% when RL = RH.)
Depends
on the
input type
RL
Minimum
value of PV
input range
EASY
Depends
on the
input type
18.2ListofParameters
