PVInputSettingMenu(Menu:PV)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange
Initial
value
SDP
PV input scale
decimal point
position
EASY
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
Depends
on the
input type
SH
Maximum
value of PV
input scale
EASY
-19999to30000,(SL<SH),|SH-SL|≤
30000
Depends
on the
input type
SL
Minimum value
of PV input
scale
EASY
Depends
on the
input type
BSL
PV input
burnout action
STD
OFF: Disable
UP: Upscale
DOWN: Downscale
Depends
on the
input type
RJC
PV input
reference
junction
compensation
PRO
OFF: RJC OFF
ON: RJC ON
ON
ERJC
PV input
external RJC
setpoint
PRO -10.0 to 60.0 (°C) 0.0
A.BS
PV analog
input bias
STD
-100.0 to 100.0% of PV input range span
(EUS)
0.0 % of
PV input
range
span
A.FL
PV analog
inputlter
STD OFF, 1 to 120 s OFF
InputRange/SPLimiterSettingMenu(Menu:MPV)
Parameter
symbol
Name
Display
level
Settingrange Initial value
P.UNI
Control PV input
unit
STD
-: No unit
C: Degree Celsius
-: No unit
--: No unit
---: No unit
F: Degree Fahrenheit
Same as PV
input unit
P.DP
Control PV input
decimal point
position
STD
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
Depends on
the input type
P.RH
Maximum value of
control PV input
range
STD
-19999 to 30000, (P.RL<P.RH), |
P.RH-P.RL|≤30000
Depends on
the input type
P.RL
Minimum value of
control PV input
range
STD
Depends on
the input type
SPH SP high limit STD
0.0 to 100.0% of PV input range
(EU), (SPL<SPH)
Place limits on the program setpoints
or the local setpoints when the
controller is in program operation.
* Places the limit on the program
setpoint, local setpoint during
program operation.
* When LP2 lamp is on, SPH
and SPL limit the program
setpoint for program pattern 2
retransmission.
* This does not work when
a program pattern is being
created.
100.0 % of PV
input range
SPL SP low limit STD
0.0 % of PV
input range
