YOKOGAWA UP35A User Manual

14
All Rights Reserved. Copyright © 2010, Yokogawa Electric Corporation
GS 05P02D41-01EN Mar.14,2016-00
nExternalDimensionsandPanelCutoutDimensions
UP35A
(25)
(53)
[(N-1)×96+92]
117 min.
145
min.
+0.8
0
+0.8
0
92
+0.8
0
92
+0.8
0
92
“N” stands for the number of controllers to be
installed.
However, the measured value applies if N≥5.
65
20
11
1 to 10 mm (panel thickness)
Bracket
Bracket
94.6 91.6
105.2
96
96
• General mounting • Side-by-side close mounting
Terminal cover (option)
Normal tolerance:
±(value of JIS B 0401-1998 tolerance class IT18)/2
UP32A
[(N-1)×48+45]
+0.6
0
+0.8
0
92
65
48
11
1 to 10 mm (panel thickness)
Bracket
Bracket
Terminal cover (option)
94.6
96
105.2
70 min.
(25)
145
min.
+0.6
0
45
(53)
+0.8
0
92
• General mounting
• Side-by-side close mounting
20
91.6
“N” stands for the number of controllers to be
installed.
However, the measured value applies if N≥5.
Normal tolerance:
±(value of JIS B 0401-1998 tolerance class IT18)/2
