YOKOGAWA UP35A User Manual

15
All Rights Reserved. Copyright © 2010, Yokogawa Electric Corporation
GS 05P02D41-01EN Mar.14,2016-00
nModelandSufxCode
Model Sufxcode
Option
code
Description
UP35A
Program Controller (Power supply: 100-240 V AC)
2programpatterns/20programsegments(Whenthe/APoptionisspecied,4
program patterns/40 program segments, max. 20 segments per pattern.)
(provided with retransmission output or 15 V DC loop power supply, 3 DIs, and
3 DOs)
Type 1:
Basic control
-0
Standard type
-1
Position proportional type
-2
Heating/cooling type
Type 2:
Functions
0
None
1
5 additional DIs, 5 additional DOs
Type 3:
Open networks
0
None
1
RS-485communication(Max.38.4kbps,2-wire/4-wire)
2
Ethernet communication (with serial gateway function)
3
CC-Linkcommunication(withModbusmasterfunction)
4
PROFIBUS-DPcommunication(withModbusmasterfunction)
5
DeviceNetcommunication(withModbusmasterfunction)
Display language
(*1)
-1
English(Default.Canbeswitchedtootherlanguagebythesetting.)
-2
German(Default.Canbeswitchedtootherlanguagebythesetting.)
-3
French(Default.Canbeswitchedtootherlanguagebythesetting.)
-4
Spanish(Default.Canbeswitchedtootherlanguagebythesetting.)
Case color
0
White (Light gray)
1
Black (Light charcoal gray)
Fixed code
-00
Always “-00” (for Standard Code Model)
Option codes
/AP
2 additional patterns/20 additional segments
/HA
Heaterbreakalarm
(*2)
/DC
Power supply 24 V AC/DC
/CT
Coating
(*3)
/CV
Terminal Cover
*1: English,German,French,andSpanishareavailablefortheguidedisplay.
*2: The/HAoptioncanbespeciedonlywhentheType1codeis"-0"or"-2."
*3: Whenthe/CToptionisspecied,theUP35Adoesnotconformtothesafetystandards(ULandCSA)andCEmarking
(Products with /CT option are not intended for EEA-market).
Model Sufxcode
Option
code
Description
UP32A
Program Controller (Power supply: 100-240 V AC)
2programpatterns/20programsegments(Whenthe/APoptionisspecied,4
program patterns/40 program segments, max. 20 segments per pattern.)
(provided with retransmission output or 15 V DC loop power supply, 3 DIs, and
3 DOs)
Type 1:
Basic control
-0
Standard type
-1
Position proportional type
-2
Heating/cooling type
Type 2:
Functions
0
None
1
RS-485communication(Max.38.4kbps,2-wire/4-wire)
2
2 additional DIs, 2 additional DOs
Type 3:
Open networks
0
None
3
CC-Linkcommunication(withModbusmasterfunction)
(*1)
Display language
(*2)
-1
English(Default.Canbeswitchedtootherlanguagebythesetting.)
-2
German(Default.Canbeswitchedtootherlanguagebythesetting.)
-3
French(Default.Canbeswitchedtootherlanguagebythesetting.)
-4
Spanish(Default.Canbeswitchedtootherlanguagebythesetting.)
Case color
0
White (Light gray)
1
Black (Light charcoal gray)
Fixed code
-00
Always “-00” (for Standard Code Model)
Option codes
/AP
2 additional patterns/20 additional segments
/HA
Heaterbreakalarm
(*3)
/DC
Power supply 24 V AC/DC
/CT
Coating
(*4)
/CV
Terminal Cover
*1: Type3code“3”canbespeciedonlywhenbothType1andType2codeare“0”.
*2: English,German,French,andSpanishareavailablefortheguidedisplay.
*3: The/HAoptioncanbespeciedonlywhentheType1codeis“-0”or“-2”andType3codeis“0”.
*4: Whenthe/CToptionisspecied,theUP32Adoesnotconformtothesafetystandards(ULandCSA)andCEmarking
(Products with /CT option are not intended for EEA-market).
