YOKOGAWA UT55A User Manual

7-2
IM 05P01C31-01EN
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
IN
PVinputtype EASY
OFF: Disable
K1: -270.0 to 1370.0 ºC / -450.0 to 2500.0 ºF
K2: -270.0 to 1000.0 ºC / -450.0 to 2300.0 ºF
K3: -200.0 to 500.0 ºC / -200.0 to 1000.0 ºF
J: -200.0 to 1200.0 ºC / -300.0 to 2300.0 ºF
T1: -270.0 to 400.0 ºC / -450.0 to 750.0 ºF
T2: 0.0 to 400.0 ºC / -200.0 to 750.0 ºF
B: 0.0 to 1800.0 ºC / 32 to 3300 ºF
S: 0.0 to 1700.0 ºC / 32 to 3100 ºF
R: 0.0 to 1700.0 ºC / 32 to 3100 ºF
N: -200.0 to 1300.0 ºC / -300.0 to 2400.0 ºF
E: -270.0 to 1000.0 ºC / -450.0 to 1800.0 ºF
L: -200.0 to 900.0 ºC / -300.0 to 1600.0 ºF
U1: -200.0 to 400.0 ºC / -300.0 to 750.0 ºF
U2: 0.0 to 400.0 ºC / -200.0 to 1000.0 ºF
W: 0.0 to 2300.0 ºC / 32 to 4200 ºF
(Note1)
PL2: 0.0 to 1390.0 ºC / 32.0 to 2500.0 ºF
P2040: 0.0 to 1900.0 ºC / 32 to 3400 ºF
WRE: 0.0 to 2000.0 ºC / 32 to 3600 ºF
JPT1: -200.0 to 500.0 ºC / -300.0 to 1000.0 ºF
JPT2: -150.0 to 150.0 ºC / -200.0 to 300.0 ºF
PT1: -200.0 to 850.0 ºC / -300.0 to 1560.0 ºF
PT2: -200.0 to 500.0 ºC / -300.0 to 1000.0 ºF
PT3: -150.00 to 150.00 ºC / -200.0 to 300.0 ºF
0.4-2V:0.400to2.000V
1-5V:1.000to5.000V
4-20: 4.00 to 20.00 mA
0-2V:0.000to2.000V
0-10V:0.00to10.00V
0-20 : 0.00 to 20.00 mA
-1020:-10.00to20.00mV
0-100:0.0to100.0mV
PV
RSP remote input type
(Note2)
EASY
0.4-2V:0.400to2.000V
1-5V:1.000to5.000V
0-2V:0.000to2.000V
0-10V:0.00to10.00V
0-125:0.000to1.250V
RSP
AIN2 aux. analog input
type
EASY AIN2
AIN4 aux. analog input
type
EASY AIN4
UNIT
PVinputunit EASY
-: No unit
C: Degree Celsius
-: No unit
- -: No unit
- - -: No unit
F: Degree Fahrenheit
PV
RSP remote input unit EASY RSP
AIN2 aux. analog input
unit
EASY AIN2
AIN4 aux. analog input
unit
EASY AIN4
Note1:W:W-5%Re/W-26%Re(HoskinsMfg.Co.).ASTME988
WRE: W97Re3-W75Re25
Note2:Forremoteinputwiththeoptionalsuffixcode/DR,RSPremoteinputtypeissameasPV
input type.
7.1SettingFunctionsofPVInput,RemoteInput,andAuxiliaryAnalogInput
