13.1.4 ChangingEventDisplay
Description
TheUT55Ahaseight
event(EV)lamps.TheUT52Ahasfourevent(EV)lamps.
ThedefaultvaluesareassignedtoEV1toEV8lampsonthefrontofthecontroller
according to each control mode.
Thealarms1
to8areassignedtoEV1toEV8inthecontrolmodesotherthanCascade
control.
Thealarms1
to8areassignedtoEV1toEV8ofLoop1,andtheLoop-2alarms1to8
areassignedtoEV1toEV8ofLoop2(theLP2lampislit)inCascadecontrol.
Loop-2EVlampsarelitwhenthecontrolmodeiscascadeandtheoperationmodeis
automatic or manual.
Setting Details
Parameter
symbol
Name
Display
level
Setting range
Menu
symbol
EV1to
EV8
EV1toEV8
display
condition
registration
PRO
Setting range: 4001 to 6304
OFF: Disable
4321: Link to alarm 1 (Lit when the alarm occurs)
4322: Link to alarm 2 (Lit when the alarm occurs)
4323: Link to alarm 3 (Lit when the alarm occurs)
4325: Link to alarm 4 (Lit when the alarm occurs)
4326: Link to alarm 5 (Lit when the alarm occurs)
4327: Link to alarm 6 (Lit when the alarm occurs)
4329: Link to alarm 7 (Lit when the alarm occurs)
4330: Link to alarm 8 (Lit when the alarm occurs)
4337: Link to Loop-2 alarm 1 (Lit when the alarm occurs)
4338: Link to Loop-2 alarm 2 (Lit when the alarm occurs)
4339: Link to Loop-2 alarm 3 (Lit when the alarm occurs)
4341: Link to Loop-2 alarm 4 (Lit when the alarm occurs)
4342: Link to Loop-2 alarm 5 (Lit when the alarm occurs)
4343: Link to Loop-2 alarm 6 (Lit when the alarm occurs)
4345: Link to Loop-2 alarm 7 (Lit when the alarm occurs)
4346: Link to Loop-2 alarm 8 (Lit when the alarm occurs)
4529: Heater break alarm 1 (Lit when the alarm occurs)
4530: Heater break alarm 2 (Lit when the alarm occurs)
5025 to 5027: Link to DI1-DI3 (Lit when the
contact is closed)
5041 to 5046: Link to DI11-DI16 (E1-terminal
area) (Lit when the contact is closed)
5057 to 5062: Link to DI21-DI26 (E2-terminal
area) (Lit when the contact is closed)
5073 to 5077: Link to DI31-DI35 (E3-terminal
area) (Lit when the contact is closed)
5089 to 5094: Link to DI41-DI46 (E4-terminal
area) (Lit when the contact is closed)
5153 to 5155: Link to AL1-AL3 (Lit when the
contact is closed)
5169 to 5173: Link to DO11-DO15 (E1-terminal
area) (Lit when the contact is closed)
5185 to 5189: Link to DO21-DO25 (E2-terminal
area) (Lit when the contact is closed)
5201 to 5205: Link to DO31-DO35 (E3-terminal
area) (Lit when the contact is closed)
5217 to 5221: Link to DO41-DO45 (E3-terminal
area) (Lit when the contact is closed)
For other functions, see the UTAdvanced
Series Communication Interface User’s
Manual.
DISP
Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
13.1 Setting Display Functions
To Next Page
