8.1.7 LoopControlwithPVAuto-selector,Heating/coolingLoopControlwith
PVAuto-selector,andPositionProportionalLoopControlwithPVAuto-
selector
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
CTLM Control mode STD
SGL: Single-loop control
CAS1: Cascade primary-loop
control
CAS2: Cascade secondary-loop
control
CAS: Cascade control
BUM: Loop control for backup
PVSW:Loop
controlwithPV
switching
PVSEL:LoopcontrolwithPV
auto-selector
PVHD:LoopcontrolwithPV-hold
function
CTL
 CAUTION
• Someparameterswillbeinitializedifthecontrolmode(CTLM)ischanged.
• When using the ladder program, the control mode cannot be changed.
Description
These control modes automatically select or calculate the larger, the smaller, the
average,ordif
ferenceofmultiple(twotofour)PVinputsforcontrol.
LoopcontrolwithPVauto-selectorcanbeusedforStandardtypeorHeating/coolingtype
controller.
Heating/cooling loop control with auto-selector can be used for Heating/cooling type
controller.
Position proportional loop control with auto-selector can be used for Position proportional
type controller.
► PIDcontrolandHeating/coolingcontrol:8.2SettingControlType(CNT)
DescriptionaboutLoopcontrolwithPVauto-selector
► Inputselection:7.4UsingLarger,Smaller,Average,orDifferenceofTwotoFourInputsasPV
Uptofour10-segmentlinearizerapproximation/10-segmentlinearizerbiasescanbe
used for the input unit or output unit.
The Function block diagram describes only the basic functions.
Parameter symbols in the Function block diagram describe representative parameters.
For the functions and parameters which are not described in Function block diagram, see
the following.
► Contactinputassignment:12.1SettingContactInputFunction
► Contactoutputassignment:12.2SettingContactOutputFunction
► Contactoutputassignmenttoretransmissionoutputterminal:10.1SettingControlOutputType
► Analogoutputrangechange:10.14ChangingCurrentOutputRange
