YOKOGAWA UT55A User Manual

19-2
IM 05P01C31-01EN
19.1.1 InputSpecifications
UniversalInput
• Number of inputs: 1
• Input type, instrument range, and measurement accuracy: See the table below.
Input Type InstrumentRange(°C) InstrumentRange(°F) Accuracy
Thermo-
couple
K
-270.0 to 1370.0°C -450.0 to 2500.0°F
±0.1%
ofinstrument
range±1digitfor0°Cormore
±0.2%ofinstrumentrange±1digitforlessthan0°C
±2%ofinstrumentrange±1digitforlessthan
-200.0°CofthermocoupleK
±1%ofinstrumentrange±1digitforlessthan
-200.0°CofthermocoupleT
-270.0 to 1000.0°C -450.0 to 2300.0°F
-270.0 to 500.0°C -200.0 to 1000.0°F
J -200.0 to 1200.0°C -300.0 to 2300.0°F
T
-270.0 to 400.0°C -450.0 to 750.0°F
0.0 to 400.0°C -200.0 to 750.0°F
B 0.0 to 1800.0°C 32 to 3300°F
±0.15%
ofinstrument
range±1digitfor400°Cor
more
±5%ofinstrumentrange±1digitforlessthan
400°C
S 0.0 to 1700.0°C 32 to 3100°F
±0.15%ofinstrument
range±1digit
R 0.0 to 1700.0°C 32 to 3100°F
N -200.0 to 1300.0°C -300.0 to 2400.0°F
±0.1%ofinstrument
range±1digit
±0.25%ofinstrumentrange±1digitforlessthan0°C
E -270.0 to 1000.0°C -450.0 to 1800.0°F
±0.1%ofinstrumentrange±1digitfor0°Cormore
±0.2%ofinstrumentrange±1digitforlessthan0°C
±1.5%ofinstrumentrange±1digitforlessthan
-200.0°CofthermocoupleE.
L -200.0 to 900.0°C -300.0 to 1600.0°F
U
-200.0 to 400.0°C -300.0 to 750.0°F
0.0 to 400.0°C -200.0 to 1000.0°F
W 0.0 to 2300.0°C 32 to 4200°F ±0.2%
ofinstrumentrange±1digit(Note2)
Platinel 2 0.0 to 1390.0°C 32.0 to 2500.0°F ±0.1%ofinstrumentrange±1digit
PR20-40 0.0 to 1900.0°C 32 to 3400°F
±0.5%ofinstrument
range±1digitfor800°Cor
more
Accuracyisnotguaranteedforlessthan800°C.
W97Re3-
W75Re25
0.0 to 2000.0°C 32 to 3600°F ±0.2%ofinstrument
range±1digit
RTD
JPt100
-200.0 to 500.0°C -300.0 to 1000.0°F ±0.1%ofinstrumentrange±1digit(Note1)
-150.00 to 150.00°C -200.0 to 300.0°F ±0.1%ofinstrumentrange±1digit
Pt100
-200.0 to 850.0°C -300.0 to 1560.0°F
±0.1%ofinstrumentrange±1digit(Note1)
-200.0 to 500.0°C -300.0 to 1000.0°F
-150.00 to 150.00°C -200.0 to 300.0°F ±0.1%ofinstrumentrange±1digit
Standard signal
0.400 to 2.000V
±0.1%ofinstrumentrange±1digit
1.000 to 5.000V
4.00 to 20.00 mA
DC voltage/current
0.000 to 2.000V
0.00 to 10.00V
0.00 to 20.00 mA
-10.00 to 20.00mV
0.0 to 100.0mV
Theaccuracyisthatinthestandardoperatingconditions:23±2°C,55±10%RH,andpower
frequencyat50/60Hz.
Note1:±0.3°C±1digitintherangebetween0and100°C,±0.5°C±1digitintherangebetween
-100and200°C.
Note2:W:W-5%Re/W-26%Re(HoskinsMfg.Co.).ASTME988
19.1HardwareSpecifications
