YOKOGAWA UT55A User Manual

12-17
IM 05P01C31-01EN
ContactInput/OutputFunctions
12
12.2.2 ChangingContactTypeofContactOutput
Description
The contact type can set the action direction of contact output assigned to the function.
Setting Details
ContactOutputEquippedasStandard
Parameter
symbol
Name
Display
level
Setting range Menusymbol
AL1.D AL1 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
ALM
AL2.D AL2 contact type PRO
AL3.D AL3 contact type PRO
Note1: Nothing is displayed on Group display when each parameter is displayed.
AdditionalContactOutput
Parameter
symbol
Name
Display
level
Setting range Menusymbol
DO1.D DOn1 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
DO
DO2.D DOn2 contact type PRO
DO3.D DOn3 contact type PRO
DO4.D DOn4 contact type PRO
DO5.D DOn5 contact type PRO
Note1: When each parameter is displayed, the terminal area (E1 to E4) is displayed on Group
display according to the suffix code and optional suffix code. “n” denotes the position of the
terminalarea.(n
=1to4)
ContactOutputforControl
Parameter
symbol
Name
Display
level
Setting range Menusymbol
OR.D OUT relay contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
ALM
OR2.D
OUT2 relay contact
type
PRO
Note1: Nothing is displayed on Group display when each parameter is displayed.
Note2: OR.D and OR2.D can be used as status output when they are not used as control output.
OR2.D can be used for Heating/cooling type.
► Terminalarrangement:17.4Wiring
► Contacttype
ofHeaterbreakalarmoutput:11.7SettingHeaterBreakAlarm
12.2SettingContactOutputFunction
