YOKOGAWA UT55A - 9.4 Forcing SP to Track Remote Input (SP Tracking)

To Next Page

To Previous Page

9-5

IM 05P01C31-01EN

Auxiliary Control Functions

9.4

ForcingSPtoTrackRemoteInput(SPTracking)

Description

SP tracking function is the function to force the local setpoint (SP) to track the remote

setpoint (RSP) when the operation mode is switched from REM (remote) to LCL (local)

mode.

The

functionis

effectivetopreventabruptPVchanges.

REM → LCL mode switch

Time

REM → LCL mode switch

Time

SP tracking enabled SP tracking disabled

RSP

Setting Details

Parameter

symbol

Name

Display

level

Setting range Menusymbol

SPT SP tracking selection STD OFF, ON SPS

Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
