ModelandSuffixCodesofUT52A(forStandardmodel)
[Style:S4]
Model Suffix code
Optional
suffix
code
Description
UT52A
DigitalIndicatingController(providedwithretransmissionoutputor15VDC
looppowersupply
,3DIs,and3DOs)(Powersupply:100-240VAC)
Type 1:
Basic
control
-0 Standard type
-1 Position proportional type
-2 Heating/cooling type
Type 2:
Functions
0 None
1
Remote (1 additional aux. analog) input, 1 additional DI, and RS-485
communication (Max. 38.4 kbps, 2-wire)
2 Remote (1 additional aux. analog) input and 1 additional DI
3 2 additional DIs and 2 additional DOs
Type 3:
Open networks
0 None
Display language (*1)
-1 English
-2 German
-3 French
-4 Spanish
Case color
0 White (Light gray)
1 Black (Light charcoal gray)
Fixed code -00 Always "-00"
Optional suffix codes
/DR
Additional direct input (TC and 3-wire/4-wire RTD) and current input to
Remote (1 additional aux. analog) input, 1 DI to be deleted (*2)
/LP 24VDClooppowersupply(*3)
/HA Heater break alarm (*4)
/DC Powersupply24VAC/DC
/CT Coating (*5)
*1:
English, German, French, and Spanish can be displayed as the guide display.
*2: When “2” is specified for the
Type 2 code, the /DR option can be specified.
*3: The /LP option can be specified in the combination of Type 1 code (any of "-0" or "-1") and
Type 2 code "0."
*4: When “-0” is specified for the Type 1 code, the /HA option can be
specified.
*5: When the /CT option is specified, the UT52A does not conform to the safety standards (UL
and CSA) and CE marking.
