YOKOGAWA UT55A User Manual

vi
IM 05P01C31-01EN
ModelandSuffixCodesofUT55A(forStandardmodel)
[Style:S4]
Model Suffix code
Optional
suffix
code
Description
UT55A
DigitalIndicatingCont
roller(providedwithretransmissionoutputor15VDC
looppowersupply,3DIs,and3DOs)(Powersupply:100-240VAC)
Type 1:
Basic
control
-0 Standard type
-1 Position proportional type
-2 Heating/cooling type
Type 2:
Functions (*1)
0 None
1
Remote (1 additional aux. analog) input, 6 additional DIs, 5 additional DOs,
and RS-485 communication (Max.19.2 kbps, 2-wire/4-wire) (*2)
2
Remote (1 additional aux. analog) input, 1 additional DI, and RS-485
communication (Max.19.2 kpbs, 2-wire/4-wire) (*2)
3 5 additional DIs and 5 additional DOs
4 Remote (1 additional aux. analog) input and 1 additional DI
5
Remote (1 additional aux. analog) input, 6 additional DIs, and 5 additional
DOs
6 5 additional DIs and 15 additional DOs
7 3 additional aux. analog inputs and 3 additional DIs
Type 3:
Open networks
0 None
1 RS-485 communication (Max.38.4 kbps, 2-wire/4-wire)
2 Ethernet communication (with serial gateway function)
3 CC-Link communication (with Modbus master function)
4 PROFIBUS-DP communication (with Modbus master function)
5 DeviceNet communication (with Modbus master function)
Display language (*3)
-1 English
-2 German
-3 French
-4 Spanish
Case color
0 White (Light gray)
1 Black (Light charcoal gray)
Fixed code -00 Always "-00"
Optional suffix codes
/DR
Additional direct input (TC and 3-wire/4-wire RTD) and current input to
Remote (1 additional aux. analog) input, 1 DI to be deleted (*4)
/LP 24VDClooppowersupply(*5)
/HA Heater break alarm (*6)
/DC Powersupply24VAC/DC
/CT Coating (*7)
*1:
When “1” or “6” is specified for the Type 2 code, only “0” can be specified for the
Type 3
code.
*2: When the /LP option is specified, the RS-485 communication for “1” or “2” of the T
ype 2
code is 2-wire system.
*3: English, German, French, and Spanish can be displayed as the guide display.
*4: When any of “1,” “2,” “4,” “5,” or “7” is specified for the Type 2 code, the /DR option can be
specified.
*5: The /LP option can be specified in the combination of Type 2 code (any of "0," "2," "3," or
"4") and Type 3 code (any of "0" or "1"). Additionally, the /LP option can be specified in the
combination of Type 2 code "1" and Type 3 code "0."
*6: When “-0” is specified for the Type 1 code, the /HA option can be specified.
*7: When the /CT option is specified, the UT55A does not conform to the safety standards (UL
and CSA) and CE marking.
