YOKOGAWA UT55A User Manual

18-8
IM 05P01C31-01EN
18.2 ListofParameters
18.2.1 OperationParameters
OperationModeMenu(Menu: MODE)
Parameter
symbol
Name
Display
level
Setting range Initialvalue
C.A.M
CAS/AUTO/MAN
switch
EASY
CAS: Cascade mode
AUTO: Automatic mode
MAN: Manual mode
* Parameter C.A.M is displayed
when the control mode is
Cascade control or Cascade
secondary-loop control.
MAN
S.R STOP/RUN switch EASY
STOP: Stop mode
RUN: Run mode
Preset output (PO) is generated in
STOP mode.
Default: Not displayed. STOP/RUN
switch is assigned to contact input.
RUN
R.L
REMOTE/LOCAL
switch
EASY
LCL: Local mode
REM: Remote mode
Select a remote input method for
acquiring the target setpoint from
remote input or communication
using the parameter RMS.
LCL
AT Auto-tuning switch EASY
OFF: Disable
1 to 8: Perform auto-tuning. Tuning
result
isstored
inthespecied
numbered PID.
R: Tuning result is stored in the
PID for reference deviation.
OFF
SPNO.
SP number
selection
EASY
1 to 8 (Depends on the setup
parameter SPGR. setting.)
1
PID PID number EASY
The PID group number being
selected is displayed.
1 to 8, R: PID group for reference
deviation
1
In Cascade control, the following operation modes are also displayed for secondary loop. (the LP2
lamp is lit)
• Operation mode: R.L, AT, PID
