11-18
IM 05P01C31-01EN
11.5 SettingAlarmOutputtoControlRelayTerminal
Description
The control relay terminal can be used for alarm output when it is not used for control
output.
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
OR.S
OUT relay function
selection
STD
Same as the setpoint for the
contact output function.
See 12.2.1, “Setting Function of
Contact Output.”
ALM
OR.D
OUT relay contact
type
PRO
0: Closes the contact when an
event occurs
1: Opens the contact when an
event occurs.
OR2.S
OUT2 relay
function selection
STD Same as OR.S.
OR2.D
OUT2 relay contact
type
PRO Same as OR.D
ParametersandCorrespondingTerminals
OR.S, OR.D OUT terminal
OR2.S, OR2.D OUT2 terminal
