YOKOGAWA UT55A User Manual

5-1
IM 05P01C31-01EN
QuickSettingFunction
5
5.1 SettingUsingQuickSettingFunction
Description
TheQuicksettingfunctionisafunctiontoeasilysetthebasicfunctionofthecontroller.
TheQuicksetting
functionstartswhenthepoweristurnedonafterwiring.
TheQuicksettingfunctioncanbeusedonlywhenthecontrolmodeisSingle-loop
control.Inothercontrolmodes,setthefunctionswithoutusingtheQuicksettingfunction.
Thefollowinglists
theitemstosetusingtheQuicksettingfunction.
(1) Control type (PID control, Heating/cooling control, etc.)
(2) Inputfunction(PVinput,range,scale(atvoltage/currentinput),etc.)
(3) Output function (control output type and cycle time)
Chapter5QuickSettingFunction
