ModelandSuffixCodesofUT55A(forDetailedmodel)
[Style:S4]
Model Suffix code
Optional
suffix
code
Description
UT55A
Digital Indicating Controller (provided with 3 DIs, and 3 DOs) (Power
supply:100-240V
AC)
Fixed code -NNN Always "-NNN”
Display language (*1)
-1 English
-2 German
-3 French
-4 Spanish
Case color
0 White (Light gray)
1 Black (Light charcoal gray)
Output 1 (*2) (*3)
-A Analog output (current/voltage pulse)
-R Relay output (c-contact)
-U Universal output (current/voltage pulse/relay)
-T Triac output
-P Position proportional output
Output 2 (*2) (*3)
A Analog output (current/voltage pulse)
R Relay output (c-contact)
U Universal output (current/voltage pulse/relay)
T Triac output
N None
Retransmission output /RT Retransmissionoutputor15VDCpowersupply
Heater break alarm (*3) /HA Heater break alarm
E1 terminal area (*4)
/R1 Remote (1 additional aux. analog) input and 1 additional DI
/U1 1additionaluniversalinput(TC/RTD/DCV/mA)
/X1 5 additional DIs
/Y1 5 additional DOs
/W1 2 additional DIs and 2 additional DOs
E2 terminal area (*4)
/A2 1 additional aux. analog input and 1 additional DI
/X2 5 additional DIs
/Y2 5 additional DOs
/W2 2 additional DIs and 2 additional DOs
E3 terminal area (*4) (*5)
/CH3 RS485 communication (Max. 38.4 kbps, 2-wire/4-wire)
/CC3 CC-Link communication
/PD3 PROFIBUS-DP communication
/DN3 DeviceNet communication
/ET3 Ethernet communication (with serial gateway function)
/X3 5 additional DIs
/Y3 5 additional DOs
/W3 2 additional DIs and 2 additional DOs
E4 terminal area (*4) (*5)
/A4 1 additional aux. analog input and 1 additional DI
/C4 RS485 communication (Max. 19.2 kbps, 2-wire/4-wire)
/L4 24VDClooppowersupply
/AC4
1 additional aux. analog input, 1 additional DI, and RS485 communication
(Max.19.2 kbps, 2-wire)
/LC4
24VDClooppowersupplyandRS485communication(Max.19.2kbps,
2-wire)
/X4 5 additional DIs
/Y4 5 additional DOs
/W4 2 additional DIs and 2 additional DOs
Power supply /DC Powersupply24VAC/DC
Additional treatment (*6) /CT Coating
*1:
English, German, French, and Spanish can be displayed as the guide display.
*2: For heating/cooling output, both Output 1 and Output 2 should be s
pecified. Not available when Output 2 is “N.” For
position proportional output, specify “-P” for Output 1 and “N” for Output 2.
*3: The /HA option can be specified only when the code for Output 1 and 2 is “-AN”, “-RN”, “-UN” or “-TN.”
*4: Only one option is available for each terminal area of E1 to E4.
*5:
The /L4 and /LC4 options for E4 terminal area can be specified only when the E3 terminal area option is not specified
orspecifiedanyof/CH3,/X3,/Y3or/W3.
*6: When the /CT option is specified, the UT55A does not conform to the safety standards (UL and CSA) and CE marking.
