7-13

IM 05P01C31-01EN

Input(PV,Remote,andAuxiliaryAnalog)Functions

7.2 SettingInputSamplingPeriod(ControlPeriod)

Setting Details

Parameter

symbol

Name

Display

level

Setting range Menusymbol

SMP

Input sampling period

(control period)

STD

50: 50 ms

100: 100 ms

200: 200 ms

CTL

Note:50ms;AvailablewhenthecontrolmodeisnotCascadecontrol(CTLM≠CAS)and

the following functions are not used: "SUPER" function, "SUPER 2" function.
