11-15

IM 05P01C31-01EN

AlarmFunctions

11.2 SettingNumberofAlarmGroupstoUse

Description

Up to eight alarm groups of alarm type, alarm hysteresis, alarm (On-/Off-) delay timer,

and alarm setpoint are available.

Unused alarm parameters can be hidden and their functions can be turned off.

The initial value of parameter ALNO. is “4.”

When

ALNO.=

4,forexample,onlythefourgroupsofalarmtype,PVvelocityalarmtime

setpoint, alarm hysteresis, alarm delay timer, and alarm setpoint are displayed.

Setting Details

Parameter

symbol

Name

Display

level

Setting range Menusymbol

ALNO.

Number of alarm

groups

PRO 1 to 8 CTL

Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
