9-6

IM 05P01C31-01EN

9.5

SettingControllerActionatPowerON(RestartMode)

Description

For details, see Chapter 15, “Power Failure Recovery Processing.”

Setting Details

Parameter

symbol

Name

Display

level

Setting range Menusymbol

R.MD Restart Mode STD

Set how the controller should

recover from a power failure of 5

seconds or more.

CONT: Continue action set before

power failure.

MAN: Start from MAN.

AUTO: Start from AUTO.

SYS

The preset output (PO) is output in MAN or AUTO mode.
