YOKOGAWA UT55A User Manual

5-6
IM 05P01C31-01EN
5.2 RestartingQuickSettingFunction
OncefunctionshavebeenbuiltusingtheQuicksettingfunction,theQuicksetting
function does not start even when the power is turned on. The following methods can be
usedtorestart
theQuicksettingfunction.
● SettheparameterQSM(Quicksettingmode)toONandturnonthepoweragain.
● SettheparameterIN(PVinputtype)toOFFandturnonthepoweragain.
 CAUTION
TheparametersrelatedtotherangeorscaleareinitializedifthePVinputtypeis
changed.
Changingthecontrol
mode(CTLM)allowsyoutorestarttheQuicksettingfunction.
However,becarefulbecausesomeparameterswillbeinitialized.
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
IN PVinputtype EASY OFF: Disable PV
QSM Quicksettingmode EASY
OFF: Disable
ON: Enable
SYS
