YOKOGAWA UT55A User Manual

13-15
IM 05P01C31-01EN
Display, Key, and Security Functions
13.1.10 SelectingtheInitialOperationDisplaythatAppearsatPowerON
Description
The initial Operation Display that appears when the power is turned on can be set.
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
HOME
Home Operation
Display setting
PRO
SP1: SP Display
SP2: Loop-2 SP Display
OUT1: OUT Display
OUT2: Loop-2 OUT Display
HCO: Heating/cooling OUT Display
VP:ValvePositionDisplay
MV:PositionProportional
Computation Output Display
PID1: PID Number Display
PID2: Loop-2 PID Number Display
HC1: Heater Break Alarm-1
Current Display
HC2: Heater Break Alarm-2
Current Display
PV1:PV2/PV1Display
PV2:PV1/PV2Display
PV:PVAnalogInputDisplay
RSP: RSP Analog Input Display
AIN2: AIN2 Analog Input Display
AIN4: AIN4 Analog Input Display
CS1 to CS5: SELECT Display 1 to 5
DISP
13
13.1 Setting Display Functions
