YOKOGAWA UT55A User Manual

8-95
IM 05P01C31-01EN
Control Functions
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
ZON
ZonePID
selection
STD
0: SP group number selection 1
1:ZonePID
selection(selection
byPV)
2:ZonePIDselection(selection
by target SP)
3: SP group number selection 2
4:ZonePIDselection(selection
by SP)
CTL
RP1 to RP7
Reference point 1
to 7
STD
0.0to100.0%ofPVinputrange
(EU)
(RP1≤RP2≤RP3≤RP4≤RP5
≤RP6≤RP7)
ZONE
PIDG.
Number of PID
groups
STD 1 to 8 CTL
PID
PID number
(display number)
EASY
1 to 8, R: PID group for reference
deviation
MODE
Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
Note2: A currently-used PID number is displayed for the parameter PID.
Note
When changing the setpoint of the parameter PIDG., if the setpoint of the parameter PIDN
which belongs to the SP menu is larger than that of the parameter PIDG., the PIDN setpoint is
changed to the PIDG. setpoint.
8
8.4SwitchingPID
