YOKOGAWA UT55A User Manual

10-34
IM 05P01C31-01EN
10.17Using15VDCLoopPowerSupply
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
RTS
Retransmission
output type of RET
EASY
OFF: Disable
PV1:PV
SP1: SP
OUT1:OUT(Valve
opening:0to
100%inPositionproportional
control)
LPS:15VDClooppowersupply
PV2:Loop-2PV
SP2: Loop-2 SP
OUT2: Loop-2 OUT
TSP1: Target SP
HOUT1: Heating-side OUT
COUT1: Cooling-side OUT
MV1:Positionproportionaloutput
(internal computed value)
TSP2: Loop-2 target SP
HOUT2: Loop-2 heating-side OUT
COUT2: Loop-2 cooling-side OUT
MV2:Loop-2positionproportional
output (internal computed
value)
PV:PVterminalsanaloginput
RSP: RSP terminals analog input
AIN2: AIN2 terminals analog input
AIN4: AIN4 terminals analog input
OUT
O1RS
Retransmission
output type of OUT
current output
EASY
O2RS
Retransmission
output type of
OUT2 current
output
EASY
ParametersandCorrespondingTerminals
RTS RET terminal
O1RS OUT terminal
O2RS OUT2 terminal
