Display, Key, and Security Functions
Setting Details
Parameter
symbol
Name
Display
level
Setting range Menusymbol
CS10 to
CS19
SELECT parameter-10
to -19 registration
PRO
OFF: No registration
D register number (2301 to
5000)
CSEL
For D register numbers, see sections 6.4.3 to 6.4.6 of UTAdvanced Series Communication Interface
User’s Manual.
D Resistor
Number
Category Description
Reference in
Communication
Interface
User's Manual
2501 to 2700
Loop-1 Operation
Parameters
SPs and alarm setpoints setting
Section 6.4.3
2701 to 2800 SP-related settings
2801 to 2900 Alarm function settings
2901 to 3000 PV
-relatedsettings
3001 to 3500 PID settings
3501 to 3600 Control action-related settings
3601 to 3800
Loop-2 Operation
Parameters
SPs and alarm setpoints setting
Section 6.4.4
3801 to 3900 SP-related settings
3901 to 4000 Alarm function settings
4001 to 4100 PV
-related
settings
4101 to 4600 PID settings
4601 to 4700 Control action-related settings
4701 to 4800 P Parameters P parameters Section 6.4.5
4801 to 5000
10-segmentLinearizer
Setting Parameters
10-segment
linearizersettings Section 6.4.6
