YOKOGAWA UT55A User Manual

17-18
IM 05P01C31-01EN
(ForDetailedmodel)UT55Aoptionalsufxcode:/W4
No-voltagecontact Transistor contact
DI41
DI42
COM
Contact rating: 12 V DC, 10 mA or more
501
502
503
DI
DI41
DI42
COM
501
502
503
DI
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
–
AdditionalContactInputAccordingtotheUT52ASuffixCodes
(ForStandardmodel)UT52Asufxcode:Type2=1 or 2
(However,whenType2=2,applicablewhenwithoutoptionalsufxcode/DR)
(ForDetailedmodel)UT52Aoptionalsufxcode:/R1or/RCH1
No-voltagecontact Transistor contact
DI16
COM
Contact rating: 12 V DC, 10 mA or more
303
304
RSP
DI16
COM
303
304
RSP
+5 V
Contact rating: 12 V DC, 10 mA or more
+
–
(ForDetailedmodel)UT52Aoptionalsufxcode:/X1
No-voltagecontact Transistor contact
DI11
DI12
DI13
DI14
DI15
COM
Contact rating: 12 V DC, 10 mA or more
301
302
303
304
305
306
DI
DI11
DI12
COM
DI13
DI14
DI15
301
302
303
304
305
306
DI
+5 V
+5 V
+5 V
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
+
+
+
–
(ForStandardmodel)UT52Asufxcode:Type2=3
(ForDetailedmodel)UT52Aoptionalsufxcode:/W1
No-voltagecontact Transistor contact
DI11
DI12
COM
Contact rating: 12 V DC, 10 mA or more
301
302
303
DI
DI11
DI12
COM
301
302
303
DI
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
–
17.4 Wiring
