QuickSettingFunction
5
SettingExample
Set the following parameters to set to PID control, thermocouple Type K (range: 0.0 to
500.0ºC), and current control output. No need to change the parameters other than the
following parameters.
Set
QSM=
YEStoenterthequicksettingmode.
(1)SetCNT=PID.
(2)SetIN=K1.
(3)SetUNIT=C(initialvalue).
(4)SetRH=500.0.
(5)SetRL=0.0.
(6)SetOT=00.02
SetEXIT=YEStoquitthequicksettingmode.
The Operation Display is shown.
Setting Details
Control Type
Parameter
symbol
Name
Display
level
Setting range Menusymbol
CNT Control type EASY
PID: PID control
ONOF: ON/OFF control (1 point of
hysteresis)
ONOF2: ON/OFF control (2 points
of hysteresis)
2P2L: Two-position two-level
control
H/C: Heating/cooling control
S-PI: Sample PI control
BATCH: Batch PID control
FFPID: Feedforward control
CTL
Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
► Controltype:8.2SettingControlType(CNT)
5.1SettingUsingQuickSettingFunction
