B - 4 MP7000 Scanner Scale Integrator Guide
Peripherals and Accessories
Customer Side Scanner (CSS) Allows self-scanning of barcodes on mobile phones, loyalty cards, and
impulse buy items
Scale Display Enables indication of zero status and gross weight indication for both
customer and operator.
Scale (Optional) Both single-interval and dual-interval options are available
Checkpoint Interlock Cable Assembly Kit p/n MX306-SA00WW - Horizontal Checkpoint antenna
p/nMX307-SA00WW - Vertical Checkpoint antennna
Width Extender (trim piece) Only for MP70XX long versions; p/n: MX303-SB-05
Table B-1 MP70XX Technical Specifications
Item Description

Zebra MP7000 Specifications

General

Type	Built-in bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, Discrete 2 of 5, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, JAN, MSI, Plessey, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code
Input voltage	90 - 264 V
Input frequency	47 - 63 Hz
Power source type	AC, RS-232, USB
Power consumption (standby)	3 W
Power consumption (typical)	5.5 W
Standard interfaces	RS-232, RS-485, USB
Connectivity technology	Wired
Keys quantity	4 keys
Product color	Black, Stainless steel
LED indicators	Yes
Image formats supported	BMP, JPEG
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	128 mm
Weight	5700 g
