Z8 Microcontrollers
ZiLOG Instruction Descriptions and Formats
UM001601-0803 12-41
LDCI
LOAD CONSTANT AUTO-INCREMENT
LDCI
Load Constant Auto-increment
LDCI dst, src
Instruction Format:
Operation:
dst <— src
r <— r + 1
rr <— rr + 1
This instruction is used for block transfers of data between program memory and the Register File. The address of
the program memory location is specified by a Working Register Pair, and the address of the Register File location
is specified by Working Register. The contents of the source location are loaded into the destination location. Both
addresses in the Working Registers are then incremented automatically. The contents of the source operand are not
affected.
Example:
If Working Register Pair R6-R7 contains 30A2H, program memory location 30A2H and 30A3H contain 22H and
BCH respectively, and Working Register R2 contains 20H, the statement:
LDCI @R2, @RR6
Op Code: C3 26
loads the value 22H into Register 20H. Working Register Pair RR6 is incremented to 30A3H and Working Register
R2 is incremented to 21H. A second
LDCI @R2, @RR6
Op Code: C3 26
loads the value BCH into Register 21H. Working Register Pair RR6 is incremented to 30A4H and Working Register
R2 is incremented to 22H.
Cycles
OPC
Address Mode
(Hex)
dst src
18 D2 Irr Ir
18 C2 Ir Irr
OPC
OPC
dst src
src dst
Flags: C: Unaffected
Z: Unaffected
S: Unaffected
V: Unaffected
D: Unaffected
H: Unaffected
